Bandwidth 50MHz
Accuracy +/- 1%
Output Voltage
Swing (into 5kohm load) +/-7V
Offset (typical) <+/-2mV(SI-50), +/-1mV(SI-51)
Noise (typical) 0.7mVrms(SI-50), 1mVrms(SI-51)
Source Impedance (typical) 50 ohm
CMRR (typical) -90dB@60Hz; -55dB@1MHz
Power Requirements
Standard 6VDC/90mA or 9VDC/70mA mains adaptor
Options Removable battery pack or power leads
Length of BNC Cable 125cm
Length of Input Leads 50cm
Weight 300g
Dimensions(LxWxH) 111mm x 22mm x 14mm

Specifications
SI-50
SI-51
Attenuation Ratio
1/10
1/100
Input Impedance
each side to ground
1.6Mohm/7pf
4Mohm/7pf
Differential Input Voltage
(DC+Peak AC)
+/-70V
+/-700V
Common Mode Voltage
(DC+Peak AC)
+/-700V
+/-1400V
Absolute Max. Input
(Each side to ground)
600Vrms CAT I
600Vrms CAT II

Features:
High Accuracy(+/-1%)
Best CMRR in Power Measurement Probes
Smallest Size
Safety Certified

Applications:
Precise Power Semiconductor Device Measurement
Switching Power Supply Design
Precise Measurement of Power Converter
Precise Measurement of Motor Drive
